3D Adjustable Invisible Hinge — 120 kg
HC-185-28
Concealed, three-dimensionally adjustable hinge in SUS304 for flush door installations, invisible when the door is closed. Opens to 180°, non-handed, and carries up to 120 kg on two hinges (a third hinge adds 20% capacity). For doors of 35 mm and thicker.
Specifications
| Parameter | Value |
|---|---|
| Door types | Wood, casting, steel and aluminium frames |
| Min. door thickness | 35 mm |
| Opening angle | Up to 180° |
| Handing | Non-handed |
| Material | SUS304 stainless steel |
| Load capacity | Up to 120 kg (2 hinges; a 3rd hinge adds 20%) |
| Adjustment (H / side / depth) | ±3 mm / ±3 mm / ±2 mm |
| Size (H × W × T) | 185 mm × 28 mm × 39.2 mm |
| Standards | UL 10C (fire rating 3 hours) |
| Finishes | Matt Chrome |
Technical Documents
Datasheets, CAD files and finish samples are available on request.
