Recognized Concealed Hinge — Zamak
HC-ZM
Concealed hinge in Zamak for interior doors of 38 mm and thicker. Opens to 180° with depth, side and height adjustment. Load capacities are specified for a 926 × 2040 mm door; the number of hinges depends on door size and weight.
Specifications
| Parameter | Value |
|---|---|
| Material | Zamak |
| Min. door thickness | 38 mm |
| Opening angle | 180° |
| Max door weight | 2 hinges: 60 kg · 3 hinges: 80 kg |
| Adjustment (depth / side / height) | 1.5 mm / ±1 mm / ±2 mm |
| Load reference | Door size 926 × 2040 mm — see load capacity tables |
| Finishes | Matt Chrome |
Technical Documents
Datasheets, CAD files and finish samples are available on request.
